Fluke TC01A, iSEE Mobile Thermal Camera (Android)

  • Fluke iSEE Mobile Thermal Camera (9Hz)*
  • This model is suitable for ANDROID devices (with USB-C connector)
  • Best-in-class mobile thermal camera

*Requires suitable mobile device (not included)

Regular Price £549.60 Special Price £478.80 £399.00

Availability: Usually 5 working days

Product Code
FLUTC01A-9HZ

Free Delivery

90-day Returns

Technical Support

Fluke iSee™ Mobile Thermal Camera - TC01A for Android (USB-C), 9 Hz.

Experience fast and easy inspections on the go!  It takes only a second to start using. The wide temperature measurement range, from -10°C up to 550°C, makes the Fluke TC01A suitable for various applications, including inspecting electrical cabinets, identifying HVAC issues, and installing underfloor heating.

Fluke iSee mobile plug-in thermal imaging cameras boast professional-grade image quality, comparable to high-end thermal cameras, with a 256 x 192 pixel thermal resolution and smooth video recording and all weighing in at just 22g.

Additionally, the Fluke software offers comprehensive spot, line, and area temperature analysis for precise diagnostics.



Who is this good for?

The Fluke TC01A is suitable for building technicians working with electrical, HVAC, and mechanical equipment for troubleshooting and maintenance.

Best-in-class mobile thermal camera that provides portable thermal imaging with unprecedented performance in measurement for fast measurements on a wide variety of electrical and mechanical equipment.



Key features

  • Lightweight portability weighing in just 22g
  • Industry leading resolution of 256 x 192 pixels (49,152 measurement points)
  • Thermal sensitivity of 50 mK
  • Temperature range up to 550 °C giving you the ability to inspect a broad range of equipment and installations

** Please ensure you purchase the correct version for your device.  This TC01A plug-in thermal camera is compatible for use only with Android devices (fitted with a USB-C connector). **



Software

The Fluke iSee™ App is where users enjoy features that help them do advanced temperature analysis (using spot, line, and area temperature calculations), recalibration of the camera to ensure the most accurate temperature capture, and a gallery of images for easy sharing and building of reports.

Languages supported at launch: English, Czech, Dutch, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish.



*Android™ is a registered trademark of Google, Inc  The Fluke TC01A supports Android™ 6.0 / HarmonyOS 2.0 or later and requires smartphones with OTG function enabled.

More Information
ManufacturerFluke
Manufacturer Part Number6016119
GTIN0195112129005
Included CalibrationCall for info
DatasheetDownload

Fluke TC01A

Performance Specifications

IR resolution

256 x 192

Pixel size

12 μm

Temperature range

-10 °C to 550 °C/14 °F to 1022 °F

Temperature accuracy

± 2 % of rdg or ± 2 °C/3.6 °F, whichever is greater

(@ 23 °C ± 5°C/73.4 °F ± 9 °F ambient temperature)

Temperature measurement distance

0.25 m to 5 m

(* -20 ℃/-4 °F to 10 ℃/50 °F, only for 0.25 m to 3 m)

Frame rate

9Hz

Warm-up time

1 minute

Focal length

Fixed focal length: 3.2 mm

Shutter mode

Internal

Thermal sensitivity (NETD)

50 mK

Spectral range

8 to 14 μm

Field of view (H x V)

56° x 42°

Spatial resolution

3.81 mrad

General Specifications

USB interface

Type-C

Operating temperature

0 ℃ to 40 ℃/32 °F to 104 °F

Storage temperature

30 ℃ to 60 ℃/–22 °F to 140 °F

Operating humidity

10 % to 90 % RH, non-condensing

Power consumption

350 mW (Typical)

Drop test

1 m/3.3 ft

Ingress protection

IEC 60529: IP54 (with the protective cover for Type C)

Operating altitude

2,000 m/6,562 ft

Storage altitude

12,000 m/39,370 ft

Dimensions (L x W x H)

60 x 33.5 x 11.2 mm/2.36 x 1.32 x 0.44 in

EMC Environment

International IEC 61326-1: Electromagnetic environment for portable equipments CISPR 11: Group 1, Class A

Group 1: Equipment has intentionally generated and/or uses conductively-coupled radio frequency energy that is necessary for the internal function of the equipment itself. Class A: Equipment is suitable for use in all establishments other than domestic and those directly connected to a low-voltage power supply net- work that supplies buildings used for domestic purposes. There may be potential difficulties in ensuring electromagnetic compatibility in other environments due to conducted and radiated disturbances.

Caution: This equipment is not intended for use in residential environments and may not provide adequate protection to radio reception in such environments.

Warranty

2 years
