The KEW6315 is Kewtech's compact power quality analyser with huge testing capabilities, the perfect tool for energy saving, trouble shooting and power quality control.
The KEW6315 enables you to monitor the power quality of a system, altering you to where costs could be saved and where unsafe conditions should be addressed.
All in one:
Measures data logging, harmonics, waveform and events (transients, dips, swells and interrupts).
The testers large memory also enables you to conduct extended surveys without worrying of running out of storage…we are talking years!
Reporting:
The KEW6315’s quick report facility allows you to download and produce a report in 2 minutes. You can enter daytime and night time tariffs to get the cost of the electricity used. You can even look at a subset of the data i.e. just Monday working hours.
EN 50160 automatic report – again within moments a 17 page report compares the measured data with the supply standard highlighting any errors.
KEY BENEFITS
Simultaneous measurements; Data logging, harmonics, waveform and events (transients, dips, swells and interrupts) measured all in one go
Extensive memory enables you to conduct extended surveys without worry of running out of storage
Quick report facility allows you to download and produce a report in 2 minutes and put a cost to energy used
EN 50160 automatic report - again within moments a 17 page report compares the measured data with the supply standard highlighting any errors
Intuitive user interface means that you will soon be up and running and remember the setting up procedure
Remote monitoring on PC and Android devices via Bluetooth
Simultaneous measurements of means that you do not have to do several surveyson the same site
Complies fully to IEC61010-1 CAT IV 300V, CAT III 600V, CAT II 1000V
Includes everything to get you started; KEW6315, three (KEW8130) 1000A flexi-clamps, four voltage test leads, PQA software and SD card
KEY FEATURES
High accuracy measurements +/- 0.2% Volts/Current, 0.3% Energy
Quick set up guide - on screen guides and wiring check
Instantaneous Values
Measures Flicker
Energy consumed
Demand monitor / prediction
Wave form and vector diagrams
Harmonic measurements and analyser
Displays and calculates power factor and corrective capacitors
Includes three 1000A flexi-clamps acurate down to 1A
Print screen function saves any screen, including connection diagram – for fast report writing
Fourth current channel for measured neutral current (neutral current also calculated) or earth leakage
Internal memory plus flash card memory – up to 1GB!
Digital output for use to control max demand
Two additional inputs for external sensors. For instance to monitor lighting / temperature levels
