The Fluke 1770 Series includes a one-of-a-kind system for automatically collecting measurements, ensuring that you always get the correct data. At the same time, it allows you to select and adjust specific parameters as needed. More than 500 network quality parameters are recorded with the default settings. The guided configuration makes it easy to choose the right parameters for the system you're working on. Logged data can be viewed, downloaded, and shared instantly with Fluke Energy Analyze Plus software, eliminating the need to wait for a session to end before reviewing or analyzing data.
The Fluke 1775 Three-Phase Power Quality Analyzer is a two-in-one power quality analyzer and power quality meter that logs and analyzes data and can be used to troubleshoot problems. Over 500 parameters are measured, including harmonics, dips, swells, unbalances, voltage, current, and power. Furthermore, the Fluke 1775 Three-Phase Power Quality Analyzer has a sample rate of 1MS/s and can capture transients up to 8kV. The middle model in Fluke's 1770 Series of PQAs, is ideal for energy surveys, load testing, harmonic surveys, nuisance circuit breaker tripping, power utility power quality surveys, and detecting equipment failures caused by transients.
A diverse and comprehensive automatic measurement capture ensures that you collect the correct data for the system you're working on, while also allowing you to change and adjust parameters as needed. The Fluke 1775's PQ Logging and Analysis function provides guided setups for easy configuration and measurement selection, while a streamlined user interface makes switching between measurement parameters simple. Guided setups also digitally autocorrect connection errors without requiring users to make physical probe changes. Furthermore, the Fluke 1775 Three-Phase Power Quality Analyzer allows you to create custom views, allowing you to tailor the PQA to your application.
A PQ Meter function gives you instant access to live data, allowing you to quickly identify potential problems while troubleshooting. The Fluke 1775 Three-Phase Power Quality Analyzer's large, bright touchscreen display shows data. It can be transferred to a PC via USB or Wi-Fi without interfering with power quality or energy studies.
After downloading data to a PC, you can view and share results with Fluke's Energy Analyse Plus Software. This software can also be used to generate customized reports and has a one-click function for generating EN50160/IEEE 519/GOST 33073 reports
Finally, the Fluke 1775 Three-Phase Power Quality Analyzer is powered directly via the measurement circuit, so it is not restricted by the location of power outlets or the length of extension cords.
The Fluke 1775 Three-Phase Power Quality Analyzer is designed for simplicity and efficiency, with automatic measurement capture technology, a simplified reporting platform, and an easy-to-use interface. It is ideal for electrical system troubleshooting as well as power and energy logging.
For specifications look in the Datasheet!
